Specifications For The Construction Of Disc-Type Scaffolding

Accidents caused by the collapse of scaffolding construction systems occur frequently at construction sites every year. This has little to do with the size of the project and the strength of the construction developer. Do you know the specifications for disc-type scaffolding?

The specifications for disc-type scaffolding are particularly important during the construction process. Standardized construction and construction can reduce or avoid the probability of collapse and casualties.

The product standards for disc-type scaffolding specifications are as follows:

The models of disc-type scaffolding are mainly divided into two types: Type A and Type B according to the "Safety Technical Regulations for Socket-type Disc-type Steel Pipe Brackets for Construction".

Type A: The diameter of the upright pole is 60mm, which is mainly used for heavy support, such as bridge projects. The disc matching this type of upright pole weighs 0.55kg/piece and is equipped with a 38mm lead screw.

Type B: The diameter of the upright pole is 48mm, which is mainly used in housing construction, decoration, stage lighting racks and other fields. The matching disc weighs 0.46kg/piece and is equipped with a 48mm lead screw.

Disc-type scaffolding uprights: national standard size, Q345B material, load-bearing capacity is further enhanced, the common specifications of the uprights are 500mm-3000mm, and the specification modulus is 500mm; the cross bar specification is 48 diameter, 2.5 wall thickness, Q235B material, commonly used 600mm-2400mm, and the specification modulus is 300mm.
